How do snowmobile treads work?

An automobile engine sends power through a driveshaft, which directly rotates the axle and the wheels of the car. However, a snowmobile engine links to a track drive, which rotates the tracks. The wheels on a snowmobile are essentially large gears with teeth spaced evenly with holes in the tracks.

How many miles can you get on a snowmobile track?

At 3,000 to 15,000 miles, snowmobile tracks have quite a varied lifespan. Like all other aspects of the snowmobile lifespan, how long your tracks last depends on proper maintenance and storage. With good caretaking, your tracks could last the entire life of your snowmobile!

What do snowmobile sliders do?

The slider is probably one of the most important parts of your snowmobile. Sometimes called “hyfax,” your snowmobile slider is the hard-plastic strip that is attached to the bottom of your skid rails. Your slider protects your aluminum rails from getting damaged and worn down by the tracks.

How does a TRA clutch work?

As a refresher for those that don't know, the TRA primary has three arms that swing outwards as RPM increases and swing back inwards as RPM decreases. They swing on a path guided by three ramps. These ramps are attached to the moveable sheeve of the primary clutch.

How does snowmobile steering work?

You steer a snowmobile by turning the handlebars, in much the same way as you steer a bicycle or motorcycle. The handlebars connect to a stem mounted near the front of the snowmobile, which in turn connects to skis mounted on a bracket at the bottom of the snowmobile.

What makes the track turn on a snowmobile?

The wheels on a snowmobile are essentially large gears with teeth spaced evenly with holes in the tracks. Every rotation of the gears powers the tracks and drives the snowmobile forward. The faster the engine, the faster the gears rotate, and the faster the tracks move.

What is the mag side of a snowmobile?

MAG= Magneto or generally refering to the side where the ignition/ electrical is generated.

How do you remove a snowmobile clutch without a puller?

How to Remove a Snowmobile Clutch Without a Puller

1. Flip the snowmobile on its side.
2. Remove engine housing to expose the clutch.
3. Remove clutch bolt.
4. Wrap the Grade 8 bolt or clutch bolt with Teflon tape.
5. Fill clutch bolt hole with water.
6. Insert the bolt and tighten.
7. Make repairs/replacements and then reassemble.

Are TRA clutches interchangeable?

TRA III or VII will work. The newer the better, I would look for a 09 or newer. If you stationary sheave and governor cup (very outer piece with rubber damper) are OK, the rest can be replaced for a fairly reasonable price.

What is Hyfax snowmobile?

Hyfax are essentially hard plastic strips. These strips are attached to the bottom of the rails on your skid. The skid is made up of the rear track rails of your snowmobile as well as the suspension. The function of the hyfax is to protect the aluminium rails from wearing out in the track.

How many miles do Hyfax last?

Depends on how you ride, what the snow conditions are like. Do you ride down hardpack trails at 60, or do you ride slower or never on trails. It all makes a difference. I typically get between 1500 and 2000 miles out of my hyfax.

How do you know when Hyfax is worn out?

Guest. Should be a line on the side, it's down the entire length of the hyfax. When you hit that line you are getting close to metal on metal. The index line may be a fine cut, similar to a razor blade cut.

How many miles will a 4-stroke snowmobile last?

Four stroke engines

With proper maintnance a 4 stroke snowmobile engine will last between 10,000-20,000 miles (16,000-32,000 kilometers) before the sled's engine will need work.

Why are snowmobiles so unreliable?

Snowmobiles are not considered to be reliable due to their poor engines which can stop working at any time after covering a particular distance. Besides, there are other factors like low capacity and the stroke system. Usually, the snowmobiles are good to go for up to 20000 miles without any hassle.

How many miles will a 2-stroke snowmobile last?

If we're talking the two most popular segments in the sno-mo-2-stroke market, the 600 and 800 class, we'll jump into the 600 class first. A current garden variety 600 twin engine in the popular trail/sport category can deliver up to 12,000 miles (19,000 kms) of reasonable use.

How does a snowmobile clutch puller work?

The puller's threads are farther back and a larger diameter, it threads into the clutch, and the longer unthreaded portion in front of it pushes up against the crank. As you tighten the puller, it pushes harder against the crank until the clutch pops free.

Are all Ski Doo clutch pullers the same?

Premium Member

They are the same except for the length..cut 3/8-1/2" off the tip of your old puller and you will have a e-tec puller.

How do you free up a snowmobile clutch?

If the primary clutch of your snowmobile is stuck, you can either pull it out using the standard clutch puller or you can use fluid to create a high pressure that will pop out the clutch.

What is a snowmobile PTO?

PTO is the clutch side. Left if your sitting on it.

What does the PTO side of an engine mean?

The PTO (Power Take Off) is the rear side the engine where the crankshaft transmits power to the driveshaft. In contrast, the MAG side is the front side were the flywheel magneto is attached to the engine.

What is the purpose of the ski tip handles?

Ski Tip Handle

Handy for pulling, moving, and lifting the vehicle.

Why are snowmobiles called sleds?

Sled: Because “snowmobile” is two syllables too long. Ski-Dooing: What your non-sledding buddy calls riding a snowmobile.

What is a snowmobile Carbide?

Snowmobile's carbide runner. Carbide runners are made up of carbide steel, which is the strongest one. Not only do they last long, but they also work better than regular hard bars. With regular wear bars, it is hard to steer a snowmobile on hard snow or ice.

How often should you grease a snowmobile?

To keep things cool and working smoothly, the parts are bathed in oil; it should be changed at least once per year. Drain the chaincase lube into a container and note its condition. If it's slippery, looks clean and seems to be in good shape, give yourself a high five for not neglecting the drivetrain.
